164.2 x 78.8 x 17.0 mm / 6.46 x 3.1 x 0.67 in. (for standard version)

< 288 g / 10.15 oz. (for standard version)

5.2'' IPS LTPS 1920 x 1080

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Main battery: Li-ion, rechargeable, 5000 mAh Standby: over 350 hours Continuous use: over 12 hours (depending on user environment) Charging time: 3-4 hours (with standard adaptor and USB cable)

Sound, LED indicator, vibrator

1 slot for Nano SIM card, 1 slot for Nano SIM or TF card

USB 2.0 Type-C, OTG, Type-C headphones supported

2 microphones, 1 for noise cancellation; 1 speaker; receiver

4 front keys, 1 power key, 2 scan keys, 1 multifunctional key

Light sensor, proximity sensor, gravity sensor

IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna

2G: GSM850/GSM900/DCS1800/PCS1900, 3G: WCDMA：B1/B2/B4/B5/B8, CDMA2000 EVDO: BC0, TD-SCDMA：A/F, 4G:B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A/B28B/B34/B38/B39/B40/B41

Depending on the country's ISP

Bluetooth 5.0

GPS/AGPS, GLONASS, BeiDou; internal antenna

Android 11 / 13; GMS, FOTA, Soti MobiControl, SafeUEM supported.

Chainway Software Development Kit

Java

Eclipse / Android Studio

Octa-core, 2.3GHz

3GB + 32GB, 4GB + 64GB (optional)

Supports up to 256GB Micro SD (TF) card

4 °F to 122 °F / -20 °C to 50 °C

-40 °F to 158 °F / -40 °C to 70 °C

5% RH - 95% RH non condensing

Multiple 1.8 m / 5.9 ft. drops (at least 20 times) to the concrete across the operating temperature range

1000 x 0.5 m / 1.64 ft. falls at room temperature

IP65 / IP67 per IEC sealing specifications

±15 KV air discharge, ±6 KV conductive discharge

* Operating temperature of UHF version: -20°C to 45°C

Honeywell: N4313

Zebra: SE4710 / SE4750SR / SE4750MR / SE4750DP; Honeywell: N6603; CM60

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.

*This function is optional

CM310-1 module based on Impinj E310

865-868 MHz / 920-925 MHz / 902-928 MHz

EPC C1 GEN2 / ISO18000-6C Supports Impinj Gen2X

Circular polarization (1.5 dBi)

1W ( +5 dBm to +30 dBm adjustable)

Up to 3m (depend on tags and environment)

*This function is optional

TCS1 Capacitive

12.8 × 18.0

508 dpi, 8-bit greylevel

FIPS 201, STQC

ISO 19794, WSQ, ANSI 378, JPEG2000

Support by SDK

AES, DES key encryption of the host communication channel

* This function is optional

TLK1NC02

14 X 22

508 dpi, 256 greylevel

FIPS 201, FBI

ISO19794, WSQ, ANSI 378, JPEG2000

Support by SDK

AES, DES key encryption of the host communication channel

* This function is optional

Optical Morpho CBM-E3

14 x 22

500 dpi, 256 greylevel

FIPS PIV IQS / ISO 19794-4, MINEX & FIPS 201 compliant, STQC

ISO 19794-2/4, WSQ, ANSI 378, etc.

Latex, Gelatin, Plasticine, Kapton, Transparent Film, Silicone, Rubber, Play-doh, Graphite Or Paper

FIPS 140-2 level 2, multiple security methods available, including image and templates encryption, template signature, secure tunneling, etc.

* This function is optional

5 MP *This function is optional

13 MP autofocus rear camera with flash Facial Recognition lSO19794-5 Compatible

13.56 MHz

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

M1 card (S50, S70), CPU card, NFC tags, etc.

2-4 cm

*This function is optional;

*NFC alternative to HF RFID.

ISO7816 T=0, T=1

2 slots for PSAM cards

*This function is optional

13.56 MHz

ISO14443A/B, ISO15693

M1 card (S50/S70), M0 (Ultralight),M3 (Desfire D40/D41/D81), CPU_A card,CPU_B card, ICODE II,TI2048,LRI64K, Others for customization

3-8 cm

*This function is optional; HF RFID alternative to NFC.
