160.0 x 76.0 x 17.0 mm / 6.3 x 2.99 x 0.67 in.

297 g / 10.47 oz. (device with battery)

5.5-inch high definition full display (18:9), IPS IGZO 1440 x 720

Multi-touch panel, gloves and wet hands supported

Main battery: Li-ion, rechargeable, 5200 mAh, support QC3.0 and RTC Standby: up to 490 hours (only main battery ; WiFi: up to 470h; 4G: up to 440h) Continuous use: over 12 hours (depending on user environment) Charging time: 2.5 hours (charge device by standard adaptor and USB cable)

Sound, LED indicator, vibrator

1 slot for Nano SIM card, 1 slot for Nano SIM or TF card

USB Type-C, USB 3.1, OTG, extended thimble

2 microphones, 1 for noise cancellation; 1 speaker; receiver

1 power key, 2 scan keys, 2 volume keys

Accelerometer sensor, light sensor, proximity sensor, gravity sensor

Support 802.11 a/b/g/n/ac/ax-ready/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4, IPV6, 5G PA Fast roaming: PMKID caching, 802.11r, OKC Operating Channels: 2.4G(channel 1~13), 5G(channel36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132, 136,140,144,149,153,157,161,165), Depends on local regulations Security and Encryption: WEP, WPA/WPA2-PSK(TKIP and AES), WAPI-PSK-EAP-TTLS, EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc

2G: 850/900/1800/1900 MHz 3G: CDMA EVDO: BC0 WCDMA: 850/900/1900/2100MHz TD-SCDMA: A/F(B34/B39) 4G: B1/B3/B5/B7/B8/B20/B38/B39/B40/B41

2G: 850/900/1800/1900 MHz 3G: 850/900/1900/2100 MHz 4G: B2/B4/B5/B7/B8/B12/B13/B17/B28A/B28B/B38

Bluetooth 5.0

Support Vo-LTE HD video voice call

GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna

Android 11 / 13; GMS, 90-day security updates, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported.

Chainway Software Development Kit

Java

Eclipse / Android Studio

Octa-core, 2.0 GHz

3GB + 32GB / 4GB + 64GB

Supports up to 256GB Micro SD (TF) card

-4°F to 122°F / -20 °C to 50 °C

-40°F to 158°F / -40 °C to 70 °C

5% RH - 95% RH non condensing

Multiple 1.8 m / 5.91 ft. drops (at least 20 times) to the concrete across the operating temperature range Multiple 2.4 m / 7.87 ft. drops (at least 20 times) to the concrete after installed rubber boot

1000 x 0.5 m / 1.64 ft. falls at room temperature

IP65 per IEC sealing specifications

±15 KV air discharge, ±8 KV conductive discharge

Zebra: SE4710/SE2100; Honeywell: N6603/6803FR; E3200; IA166S; CM60

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.

*This function is optional

TCS1

12.8 × 18.0

508 dpi, 8-bit greylevel

FIPS 201, STQC

ISO 19794, WSQ, ANSI 378, JPEG2000

Support by SDK

AES, DES key encryption of the host communication channel

*This function is optional

TLK1NC02

14.0 X 22.0

508dpi, 256 greylevel

FIPS 201, FBI

ISO19794, WSQ, ANSI 378, JPEG2000

Support by SDK

AES, DES key encryption of the host communication channel

*This function is optional

113MP autofocus rear camera with flash Facial Recognition lSO19794-5 Compatible

13.56 MHz

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

M1 card (S50, S70), CPU card, NFC tags, etc.

2-4 cm
