157.6 x 73.7 x 29 mm / 6.2 x 2.9 x 1.1 in.

292 g / 10.3 oz.

4'' TN α-Si 480*800, 16.7 M colors

Rugged dual touch capacitive touch panel

Main battery: Li-ion, rechargeable, 4200 mAh Standby: over 300 hours Continuous use: over 12 hours (depending on user environment) Charging time: 3-4 hours (with standard adaptor and USB cable)

Sound, LED indicator, vibrator

1 slot for Micro SIM card, 1 slot for MircoSD(TF) or PSAM card (optional)

USB 2.0, Type-C, OTG

1 microphone; 1 speaker; receiver

3 TP soft keys, 3 side keys, numeric keyboard (Optional : 20 keys)

Light sensor, proximity sensor, gravity sensor

Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4, IPV6, 5G PA; Fast roaming: PMKID caching, 802.11r, OKC; Operating Channels: 2.4G(channel 1~13), 5G(channel 36,38,40,42,44,46,48,52,56,60,64,100,104,108,112,116,120,124,128,132,136,140,149,153,157,161,165, depends on local regulations Security and Encryption: WEP,WPA/WPA2-PSK(TKIP and AES),WAPI-PSK-EAP-TTLS,EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc.

2G: GSM850/GSM900/DCS1800/PCS1900, 3G: WCDMA: B1/B2/B4/B5/B8, TD-SCDMA: A/F(B34/B39), 4G: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A/ B28B/B34/B38/B39/B40/B41

Depending on the country's ISP

V2.1+EDR, 3.0+HS and V4.1+HS, BT5.0

GPS/AGPS, GLONASS, BeiDou, internal antenna

*C6000 models being manufactured for Brazil Market, do not include 4G B7 and B38 frequency. *C6000 Wifi-Only Model available. Wifi-Only model does not include WWAN GSM_GPRS(2G,3G,4G) and sim card socket.

Android 10.0 / 13.0; GMS, Soti MobiControl (Only Android 10.0 support); FOTA, SafeUEM supported.

Chainway Software Development Kit

Java

Eclipse / Android Studio

Octa-core, 2.0GHz

3GB + 32GB

Supports up to 256GB Micro SD (TF) card

-4°F to 122°F / -20°C to 50°C

-40°F to 158°F / -40°C to 70°C

5%RH - 95%RH non condensing

Multiple 2.0 m / 6.56 ft. drops to concrete across the operating temperature range

1000 x 0.5 m / 1.64 ft. falls at room temperature

IP65 per IEC sealing specifications

±15 KV air discharge, ±6 KV conductive discharge

Zebra SE4710; Honeywell N6603

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc

*This function is optional

13MP Autofocus with Flash

13.56 MHz

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc

M1 card (S50, S70), CPU card, NFC tags, etc

2-4cm

* Pistol grip is optional, NFC can not coexist with the pistol grip

*This function is optional
