Chainway MC50 5G Mobile Computer (Android 12)

More Powerful, More Extensible, More Advanced in Every Way

Chainway MC50 is our newly launched 5G high-performance mobile computer. The top-of-the-class configuration comprises advanced Android 12, and optional ultra-large memory. It integrates barcode scanning, NFC, dual camera, and multiple wireless data connections, as well as 6-inch HD screen, high-capacity removable battery and IP67 sealing. It can bring a new level of cost efficiency to a broad range of industries including retail, logistics, and warehousing.

Get Quote Specifications

5G · Android 12 · IP67

Features

High-Performance Qualcomm Octa-Core 2.0GHz
5G IoT Chip Platform
Wi-Fi 6-Ready
5000mAh Battery with Battery Gauge
IP67 & 1.5m Drop Resistance

Functions

Powerful Barcode Scanning
Optional UHF Back Clip
Front and Rear Cameras, NFC, and More

SPECIFICATIONS

Physical Characteristics

Dimensions

161.0 x 77.8 x 15.5mm / 6.34 x 3.06 x 0.61in.

Weight

280g-288g / 9.88oz-10.16oz. (device with battery)

Display

6-inch high definition display (18:9), 1440 x 720

Touch Panel

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Power

5000mAh removable main battery, support QC3.0 and RTC

Notification

Sound, LED indicator, vibrator

Interfaces

USB Type-C, USB 3.1, OTG

Card Slot

1 for SIM card, 1 for SIM or TF card

Audio

2 microphones, 1 for noise cancellation; 1 speaker; 1 receiver; 1 multifunctional key

Keypad

Power key, 2 scan keys, volume (+/-) keys

Sensors

G-sensor, proximity sensor, light sensor, geomagnetic sensor, gyroscope

Communication

WLAN

Support 802.11 a/b/g/n/ac/ax-ready, 2.4G/5G dual-band, IPV4, IPV6, 5G PA; 2x2 MU-MIMO; Fast roaming: PMKID caching, 802.11r, OKC; Operating Channels: 2.4G (channel 1~13), 5G (channel 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165), Depends on local regulations Security and Encryption: WEP, WPA/WPA2-PSK(TKIP and AES), WAPI-PSK-EAP-TTLS, EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC, WPA3-Enterprise, WPA3-Enhanced Open, WPA3 Easy Connect, WPA3-Personal, etc.

WWAN

2G: 850/900/1800/1900MHz, 3G: 850/900/1900/2100MHz, 4G: B1/B2/B3/B5/B7/B8/B20/B28A/B28B/B34/B38/B39/B40/B41, 5G: N1/N3/N8/N28/N41/N78/N79

Bluetooth

Bluetooth 5.1

Vo-LTE

Support Vo-LTE HD video voice call

GNSS

GPS / AGPS, GLONASS, BeiDou, Galileo, internal antenna

Developing Environment

Operating System

Android 12; GMS&AER; Committed support for a future upgrade to Android 14 pending feasibility

SDK

Chainway Software Development Kit

Language

Java

Tool

Eclipse / Android Studio

Performance

CPU

Octa-core, 2.0GHz

RAM+ROM

4GB + 64GB / 6GB + 128GB

Expansion

Supports up to 256GB TF card

User Environment

Operating Temp.

-4°F to 122°F / -20°C to +50°C

Storage Temp.

-40°F to 158°F / -40°C to +70°C

Humidity

5%RH - 95%RH non condensing

Drop Specification

Multiple 1.5m / 4.92ft. drops (at least 20 times) to the concrete across the operating temperature range MIL-STD-810H(SGS Test): Multiple 1.5m drops (at least 20 times) to theplate across the operating temperature range

Tumble Specification

1000 x 0.5m / 1.64ft. falls at room temperature

Sealing

IP67 per IEC sealing specifications

ESD

±15KV air discharge, ±8KV conductive discharge

Barcode Scanner

2D Scanner

Zebra: SE4710/SE4750/SE5500; CM60

1D Symbologies

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.

Note

* This function is optional

Camera

Front Camera

5MP

Rear Camera

16MP Autofocus with flash

NFC

Frequency

13.56MHz

Protocol

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

Chips

M1 card (S50, S70), CPU card, NFC tags, etc.

Range

2-4cm
