Chainway C75 Mobile Computer with Printer

More Powerful, More Extensible, More Advanced in Every Way

Chainway C75 is a handheld computer with large display and thermal printing. It supports various types of printing cores and enables quick printing of receipts. The built-in dual slots for PSAM cards help in easy encryption of data. And it boasts superb performance, and supports optional NFC, barcode scanning, etc. This mobile computer can be used in various sectors like retail, parking and so forth.

Get Quote Specifications

Mobile Efficient Receipt Printing

Features

Android 11
Octa-core 2.3GHz
5.2'' IPS 1080P Screen
8000mAh Powerful Battery
IP54 Sealing

Functions

Thermal Printing
Optional Barcode, NFC, PSAM and More

SPECIFICATIONS

Physical Characteristics

Dimensions

186.89*83.99*35.04-49.49mm

Weight

507g/17.88oz

Display

5.2'' IPS LTPS 1920 x 1080P

Touch Panel

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Power

Main battery: Li-ion, rechargeable, 8000mAh

Notification

Sound, LED indicator

Expansion Slot

2 PSAM slots at most (ISO7816 protocol), 1 slot for Nano SIM card, 1 slot for Nano SIM or TF card

Interfaces

USB 2.0 Type-C, OTG

Audio

1 microphone; 1 speaker; receiver

Keypad

1 power key, 2 scan keys, 1 multifunctional key, numeric keyboard

Sensors

Light sensor, proximity sensor, gravity sensor

Colour

Black + White

Communication

WLAN

IEEE802.11 a/b/g/n, 2.4G/5G dual-band, internal antenna

WWAN

2G: GSM850/GSM900/DCS1800/PCS1900, 3G: WCDMA: B1/B2/B4/B5/B8, CDMA2000 EVDO: BC0, TD-SCDMA: A/F, 4G: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A/B28B/B34/B38/B39/B40/B41

Bluetooth

Bluetooth 5.0

GNSS

GPS/AGPS, GLONASS, BeiDou; internal antenna

Note

*Chainway C75 models being manufactured for Turkish Market, do not include Voice Call (Phone Call) function. WAN module included on those models only support DATA transfer.

Developing Environment

Operating System

Android 11.0; SafeUEM supported. Committed support for a future upgrade to Android 12, 13, and Android 14 pending feasibility

SDK

Chainway Software Development Kit

Language

Java

Tool

Eclipse / Android Studio

Performance

CPU

Octa-core 2.3GHz

RAM+ROM

3GB + 32G / 4GB + 64GB (optional)

Expansion

Supports up to 256GB Micro SD (TF) card

User Environment

Operating Temp.

-4°F to 122°F / -20°C to 50°C

Storage Temp.

-40°F to 158°F / -40°C to 70°C

Humidity

5%RH - 95%RH non condensing

Drop Specification

Multiple 1.5 m / 4.92 ft. drops (at least 20 times) to the concrete across the operating temperature range

Sealing

IP54

ESD

±15KV air discharge, ±6KV conductive discharge

Barcode Scanner

2D Imager Scanner

Zebra SE4710

2D Symbologies

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.

Note

*This function is optional

Camera

Camera

13MP Autofocus with flash

Thermal Printer

Rate

85 mm/s

Image Size (pixel)

384 dots

Paper Width

58 mm

Paper Diameter

3 cm

Paper Length

5.45 m

NFC

Frequency

13.56MHz

Protocol

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

Chips

M1 card (S50, S70), CPU card, NFC tags, etc.

Range

2-4cm
