164.2 x 78.8 x 17.5mm / 6.46 x 3.10 x 0.69 in.

＜321 g / 11.32 oz.

5.2'' IPS LTPS 1920 x 1080

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Main battery: Li-ion, rechargeable, 5000 mAh Standby: over 350 hours Continuous use: over 12 hours (depending on user environment) Charging time: 3-4 hours (with standard adaptor and USB cable)

Sound, LED indicator, vibrator

1 slot for Nano SIM card, 1 slot for Nano SIM or TF card

USB 2.0 Type-C, OTG, Type-C headphones supported

2 microphones, 1 for noise cancellation; 1 speaker; receiver

4 front keys, 1 power key, 2 scan keys, 1 multifunctional key

Light sensor, proximity sensor, gravity sensor

IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna

2G: GSM850/GSM900/DCS1800/PCS1900 3G: WCDMA：B1/B2/B4/B5/B8 CDMA2000 EVDO: BC0 TD-SCDMA：A/F 4G:B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A B28B/B34/B38/B39/B40/B41

Depending on the country's ISP

Bluetooth 5.0

GPS/AGPS, GLONASS, BeiDou; internal antenna

Chainway C71 models being manufactured for Turkish & Egyptian Markets, do not include Voice Call ( Phone Call ) function. WAN module included on those models only support DATA transfer.

Android 11 / 13; GMS, FOTA, Soti MobiControl, SafeUEM supported.

Chainway Software Development Kit

Java

Eclipse / Android Studio

Octa-core 2.3 GHz

3GB + 32GB / 4GB + 64GB (optional)

Supports up to 256GB Micro SD (TF) card

4 °F to 113 °F / -20 °C to 45 °C

-40 °F to 158 °F / -40 °C to 70 °C

5% RH - 95% RH non condensing

Multiple 1.8 m / 5.9 ft. drops (at least 20 times) to the concrete across the operating temperature range

1000 x 0.5 m / 1.64 ft. falls at room temperature

IP65 / IP67 per IEC sealing specifications

±15 KV air discharge, ±6 KV conductive discharge

Honeywell: N4313

Zebra: SE4710 / SE4750SR / SE4750MR / SE4750DP; Honeywell: N6603; CM60

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.

* This function is optional

CM-3N module based on Impinj E310

865-868 MHz / 920-925 MHz / 902-928 MHz

Supported

EPC C1 GEN2 / ISO18000-6C

Circular polarization (1.5 dBi)

1W (+5 dBm to +30 dBm adjustable)

3m (Impinj MR6 tag, size 70 x 15mm) 3m (Impinj M750 tag, size 70 x 15mm) 4m (Alien H3 Anti-Metal tag, size 130 x 42mm)

* Ranges are measured in the open outdoors and low interference environment, and rate is measured in a laboratory low interference environment, they are affected by tags and environment. * The UHF frequency of Egypt is 865-868 MHz.

5 MP *This function is optional

13 MP autofocus rear camera with flash Facial Recognition lSO19794-5 Compatible

13.56 MHz

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

M1 card (S50, S70), CPU card, NFC tags, etc.

2-4 cm
