250.8 x 152.0 x 15.0 mm / 9.87 x 5.98 x 0.59 in. ( for standard version )

680 g / 23.99 oz. ( for standard version )

8'' IPS LTPS 1920 x 1200

Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported

Main battery: Li-ion, rechargeable, 8700 mAh Standby: over 500 hours Continuous use: over 10 hours (depending on user environment) Charging time: 5-7 hours (with standard AC adaptor and USB cable)

Sound, LED indicator

1 slot for Micro SIM card, 1 slot for Micro SIM / TF card, Optional dual PSAM card slots

USB 2.0 Type-C, OTG

1 microphone; 1 speaker

1 front key, 1 volume key, 1 power key, direction key (Optional)

Gravity sensor; gyroscope; geomagnetic sensor; light / proximity sensor

Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4, IPV6; Fast roaming: PMKID caching, 802.11r, OKC; Operating Channels: 2.4G(channel 1~13), 5G(channel 36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128, 132,136,140,144,149,153,157,161,165),Depends on local regulations; Security and Encryption: WEP,WPA/WPA2-PSK(TKIP and AES),WAPIPSK-EAP-TTLS,EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAPGTC,etc.

2G: 850/900/1800/1900MHz, GPRS, EDGE 3G: CDMA EVDO: BC0 WCDMA: B1/B2/B5/B8 4G: TDD-LTE: B34/B38/B39/B40/B41 FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B28

Bluetooth 5.1

Support Vo-LTE HD video voice call

GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna

Android 13; GMS&AER, 90-day security updates, FOTA, Soti MobiControl, SafeUEM supported

Chainway Software Development Kit

Java

Eclipse / Android Studio

Octa-core, 2.0GHz; GMS&AER

4GB + 64GB

Supports up to 256GB Micro SD card

-4 °F to 122 °F / -20 °C to 50 °C

-40 °F to 158 °F / -40 °C to 70 °C

5% RH - 95% RH non condensing

Multiple 1.5 m / 4.92 ft. drops to concrete across the operating temperature range

500 x 0.5 m / 1.64 ft falls at room temperature

IP65 per IEC sealing specifications

±15 KV air discharge, ±8 KV conductive discharge

Zebra SE4710; Honeywell HS7

UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch, Postal (KIX), etc.

* This function is optional

CM710-1 module based on Impinj E710

865-868 MHz / 920-925 MHz / 902-928 MHz

Supported

EPC C1 GEN2 / ISO18000-6C

Circular polarization (3 dBi)

1W (30 dBm, +5 dBm to +30 dBm adjustable), 2W Optional (33dBm, for Latin America, etc.) R/W

900+ tags/sec

Up to 10 m (open outdoors, Impinj MR6 tag)

* Ranges and rates depend on tags and environment. * This function is optional

TCS1 Capacitive

12.8 × 18.0

508 dpi, 8-bit greylevel

FIPS 201, STQC

ISO 19794, WSQ, ANSI 378, JPEG2000

Support by SDK

AES, DES key encryption of the host communicationchannel

* This function is optional

TLK1NC02

14.0 X 22.0

508dpi, 256-bit greylevel

FIPS 201, FBI

ISO19794, WSQ, ANSI 378, JPEG2000

Support by SDK

AES, DES key encryption of the host communicationchannel

* This function is optional

Optical Morpho CBM-E3

14.0 X 22.0

500 dpi, 256 greylevel

FIPS PIV IQS / ISO 19794-4, MINEX & FIPS 201complaint, STQC

ISO 19794-2/4, WSQ, ANSI 378, etc.

Latex, GeLatin, Plasticine, Kapton, Transparent Film, Silicone, Rubber, Play-doh, Graphite Or Paper

FIPS 140-2 level 2, multiple security methods available, including image and templates encryption, template signature, secure tunneling, etc.

* This function is optional

5 MP

13 MP Autofocus with flash

13.56 MHz

ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

M1 card (S50, S70), CPU card, NFC tags, etc.

0-4 cm
